Electric Underfloor Heating Cost

Electric underfloor heating in the UK typically costs between £400 and £3,000 installed, depending on room size, system type, and whether existing flooring needs to be lifted. It is a popular choice for bathrooms, kitchens, and extensions.

Average cost: £400–£3000

Cost Breakdown

Item	Min	Max	Note
Mat system per m² (supply)	£30	£60	Pre-spaced heating cable on adhesive mesh; best for regular-shaped rooms
Loose cable system per m² (supply)	£20	£50	Flexible layout for irregular rooms, around obstacles; slightly cheaper
Installation per m² (labour)	£25	£50	Includes laying, connecting to supply, and basic floor prep
Thermostat (supply + fit)	£80	£250	Basic manual from £80; programmable or smart Wi-Fi thermostat up to £250
Floor preparation	£50	£300	Self-levelling compound, insulation boards, or removal of existing floor covering
Insulation boards per m²	£8	£18	Strongly recommended to direct heat upward and reduce running costs

What's Included

Supply of electric heating mat or loose cable system sized to the room
Installation of heating elements with appropriate spacing and adhesive or fixing clips
Fitting of floor temperature sensor probe within a conduit for future replacement
Supply and installation of thermostat with programming or smart connectivity
Connection to a dedicated electrical circuit at the consumer unit
Full system testing including insulation resistance, continuity, and functional heat-up check

Factors Affecting Cost

Room size: Larger areas benefit from lower per-square-metre rates, but total material and labour costs increase proportionally. A small bathroom (4 m²) will cost far less than a large open-plan kitchen (25 m²).
System type: Heating mats are quicker to install and suit regular rectangular rooms. Loose cable systems cost slightly less for materials but take longer to lay, especially in L-shaped rooms or around fixtures.
Thermostat choice: A basic manual thermostat adds around £80, while a smart thermostat with app control, scheduling, and energy monitoring can cost £200-£250 but typically pays for itself through more efficient heating.
Floor build-up and insulation: Installing insulation boards underneath the heating element is essential for efficiency. Without insulation, up to 50% of the heat can be lost downward, dramatically increasing running costs.
Existing flooring: If the current floor covering and screed need to be removed before installation, this adds significant labour time. Fitting underfloor heating during a renovation is much cheaper than retrofitting.
Electrical supply: Most electric underfloor heating systems require a dedicated circuit from the consumer unit. If a new circuit needs to be run, expect an additional £100-£200 for the electrician.
Floor finish compatibility: Tile and stone work best with underfloor heating. Engineered wood is usually suitable, but solid wood and some laminates may require lower temperature limits, affecting system design.

How Long Does It Take?

For a single room such as a bathroom (3-5 m²), electric underfloor heating can typically be installed in half a day to one full day, including laying insulation boards, fitting the heating mat, installing the thermostat, and wiring in a new circuit. A larger room of 15-20 m² may take 1-2 days. If floor preparation is needed, such as applying self-levelling compound or removing an old floor, add an extra half day. The heating system should not be switched on until any tile adhesive or levelling compound has fully cured, which is usually 7-14 days depending on the product used.

Do I Need This?

Electric underfloor heating is an excellent choice if you want comfortable, even warmth without radiators taking up wall space. It is particularly popular in bathrooms and en-suites where warm tiles underfoot are a luxury, and in kitchen extensions where radiator placement is awkward. Electric systems are generally better suited as secondary or supplementary heating for individual rooms rather than as the sole heating source for an entire house, as running costs are higher than wet (water-based) underfloor heating for large areas. If you are renovating a single room or adding a small extension, electric underfloor heating is the most cost-effective and least disruptive option. For whole-house heating in a new build, a wet system connected to a heat pump is usually more economical to run.

How to Save Money

Always install insulation boards beneath the heating element. This simple addition costs £8-£18 per m² but can reduce running costs by 30-50% by directing heat upward rather than into the subfloor.

Use a programmable or smart thermostat to heat rooms only when needed. Setting the system to warm up 30 minutes before you use the room and switching off when you leave can halve energy consumption.

Install during a renovation when the floor is already being lifted. Retrofitting underfloor heating into an existing room costs significantly more due to the need to remove and replace the floor covering.

Compare mat and loose cable systems for your specific room. Mats are quicker to install (saving on labour) for rectangular rooms, while loose cables can be more economical for smaller or irregular spaces.

Get quotes from multiple electricians and check that the quote includes all components: heating element, thermostat, insulation, floor sensor, and connection to the consumer unit.

Average Cost Summary

£400–£3000

Typical price range for electric underfloor heating cost in the UK. Prices may vary based on your location, property type, and specific requirements.

Find a Local Electrician

Need a qualified electrician? Browse all London electricians or find one in a borough near you.

Related Cost Guides

House Rewiring Cost UK 2026

How much does it cost to rewire a house in the UK? A full house rewire costs between £2,500 and £15,000 depending on property size, age, and location. A typical 3-bed house rewire costs £5,000 to £8,000, while a 2-bed house costs £3,500 to £5,500. This guide breaks down rewiring costs for every property type, explains what affects the price, and helps you budget accurately before getting quotes.

£2500–£15000

Fuse Box Replacement Cost

Replacing a fuse box (consumer unit) in the UK typically costs between £350 and £800, including the unit itself, labour, and certification. Upgrading to a modern consumer unit with RCD protection is one of the most important electrical safety improvements you can make.

£350–£800

Sources & References

Frequently Asked Questions

How much does electric underfloor heating cost to run?

Running costs depend on room size, insulation quality, and how often the system is used. As a rough guide, a 5 m² bathroom heated for 4 hours a day costs approximately £8-£12 per month at current UK electricity rates (around 24p/kWh). A well-insulated 15 m² kitchen used for 6 hours a day might cost £25-£40 per month. Using a programmable thermostat and insulation boards significantly reduces these costs.

Can underfloor heating be used under any type of flooring?

Electric underfloor heating works best under tile, stone, and porcelain, which conduct heat well. Engineered wood, luxury vinyl tile (LVT), and most laminates are also suitable, though you should check the manufacturer's maximum temperature rating. Solid hardwood is generally not recommended as it can warp and crack with temperature changes. Thick carpet with heavy underlay acts as an insulator and makes underfloor heating inefficient.

Is electric or water underfloor heating better?

Electric (dry) systems are cheaper and faster to install, have a thinner profile (adding only 3-6 mm to floor height), and are ideal for single rooms or retrofitting. Water (wet) systems are cheaper to run for large areas because they use hot water from a boiler or heat pump, but they are thicker (adding 50-100 mm), more expensive to install, and far more disruptive. For a single bathroom or kitchen, electric is almost always the better choice. For a whole-house new build, wet systems are more cost-effective long-term.

Do I need building regulations approval?

The electrical connection for underfloor heating is notifiable work under Part P of the Building Regulations in England and Wales. If a qualified electrician registered with a competent person scheme (such as NICEIC or NAPIT) carries out the work, they will self-certify and issue a Building Regulations compliance certificate. If you use an unregistered electrician, you will need to apply to your local authority for Building Control approval, which costs extra and takes longer.

How long does electric underfloor heating last?

Quality electric underfloor heating systems have a lifespan of 25-30 years or more. The heating element itself is sealed and has no moving parts, so it rarely fails. Most reputable manufacturers offer warranties of 15-25 years on the heating cable. The thermostat and floor sensor may need replacing after 10-15 years, but these are inexpensive and accessible components.

Can I install electric underfloor heating myself?

You can lay the heating mat or cable yourself as a DIY project, which saves on labour costs. However, the final electrical connection to the consumer unit and thermostat must be carried out by a qualified electrician to comply with Building Regulations Part P. Many homeowners lay the mat themselves and then have an electrician come in for a half-day to do the wiring, testing, and certification.

Will underfloor heating raise my floor height?

Electric underfloor heating adds very little to floor height. A heating mat system is typically only 3-4 mm thick, and even with insulation boards the total build-up is usually 10-15 mm. This is generally manageable at doorways with a transition strip or a slight threshold adjustment. By comparison, wet underfloor heating systems add 50-100 mm, which often requires significant floor and door modifications.

Can underfloor heating replace radiators entirely?

In a well-insulated room, electric underfloor heating can provide sufficient warmth as the sole heat source, but this depends on the room's heat loss calculation. For bathrooms and small rooms it usually works well as primary heating. For larger living spaces or older properties with poor insulation, underfloor heating may need to be supplemented with other heating. An electrician or heating engineer can carry out a heat loss assessment to confirm whether underfloor heating alone will be adequate.
