Electric Gate & Barrier Installation
Professional electric gate installation for homes and businesses. Swing and sliding gates, safety compliance, intercom integration, and force testing. Qualified and insured.
Get a quote
Electric Gate & Barrier Installation
Qualified electrician
Same-day service
Most jobs matched within hours.
Upfront pricing
Clear quotes before work starts.
Qualified pros
NICEIC & NAPIT registered.
Pay when done
Funds held until you're happy.
How it works
Site survey and gate assessment
The installer assesses the existing gate (or specifies a new one), the driveway gradient, available space for gate swing or slide, pillar/post condition, power supply availability, and drainage. They recommend swing or sliding automation based on the site constraints and discuss access control options (remote, keypad, intercom, or app).
Power supply installation
An outdoor-rated power supply is installed near the gate position. This typically involves running an armoured cable (SWA) from the consumer unit to a weatherproof enclosure at the gate. The circuit is protected by an appropriately rated RCBO. Some low-voltage systems can use a plug-in transformer, but mains supply is more reliable for heavy gates.
Motor and mechanism installation
The gate motor is installed: ram or articulated arm operators for swing gates (mounted on the gate pillars), or a rack-and-pinion track motor for sliding gates. Underground motors are set in foundation boxes. The control panel is mounted in a weatherproof enclosure and connected to the motor, power supply, and safety devices.
Safety device installation
Photocells are installed at appropriate heights to detect people and vehicles in the gate path. Pressure-sensitive safety edges are fitted to the leading and closing edges of the gate to detect obstruction on contact. An obstacle detection system is configured in the control panel to reverse the gate if resistance is encountered during travel.
Access control and intercom integration
Remote controls (key fobs) are programmed and paired with the control panel. If specified, a keypad, intercom, or video entry system is installed at the gate entrance and integrated with the gate controller. App-based access (via GSM module) is configured for remote opening from a smartphone.
Force testing, commissioning, and handover
The installer performs a force test to BS EN 12445, measuring the force exerted by the gate at various points during its travel. Results must fall within the limits specified in BS EN 12453. A risk assessment, force test certificate, Declaration of Conformity, user manual, and maintenance schedule are provided. The installer demonstrates safe operation and emergency manual release.
What's included
What's involved
An electric gate system automates your driveway or entrance gate with a motor, control panel, safety sensors, and remote access. Installation covers the complete system: gate motor (swing arm, underground, or sliding track), safety edges and photocells to prevent entrapment, intercom or keypad integration, and remote controls. Electric gates are classed as machinery under UK law — they must be installed to strict safety standards and undergo documented force testing before handover.
Electric gates are legally classified as machinery and must comply with the Supply of Machinery (Safety) Regulations 2008. An incorrectly installed gate can trap, crush, or injure people — particularly children. The installer must carry out a force test to BS EN 12445, install appropriate safety devices (photocells, safety edges, obstacle detection), produce a Declaration of Conformity, and affix a CE/UKCA plate. DIY motorisation of existing gates is strongly discouraged — improper safety measures have resulted in fatalities. A professional gate installer ensures legal compliance, safe operation, and reliable performance.
Get a personalised quote
Typical cost: £1,500–£5,000per installation
Every job is different — pricing depends on your property, location, and specific requirements. Describe what you need and a qualified electrician will quote you directly.
How long does it take?
Automating existing gates with a standard swing motor takes 1-2 days. A full installation including new gates, sliding motor, power supply, and intercom typically takes 2-3 days. Underground motor installations may add an extra day for groundwork.
Regulations & safety
Safety notice
Electric gates have caused fatalities in the UK, including deaths of children. The leading and closing edges of the gate must be fitted with pressure-sensitive safety edges, and photocell beams must protect the gate opening. Never operate a gate without functioning safety devices.
Every electric gate must have an accessible manual release mechanism that allows the gate to be opened by hand during power failure or emergency. Ensure all household members know how to use it.
Gate force testing to BS EN 12445 is not optional — it is a legal requirement under the Supply of Machinery (Safety) Regulations 2008. The installer must provide a documented force test certificate and Declaration of Conformity before handover.
Supply of Machinery (Safety) Regulations 2008
Electric gates are classified as machinery. The installer (as the person who makes the gate system available for use) is the 'responsible person' and must ensure the complete system complies with the essential health and safety requirements. A Declaration of Conformity and CE/UKCA marking are mandatory.
BS EN 12453 (Industrial, Commercial, and Garage Doors and Gates — Safety in Use)
Specifies the safety requirements for power-operated gates, including maximum permissible forces, safety device requirements, and control system behaviour. The standard defines four types of gate use and the corresponding safety measures required for each.
BS EN 12445 (Industrial, Commercial, and Garage Doors and Gates — Safety in Use — Test Methods)
The companion test standard to BS EN 12453. Specifies how force testing must be carried out, including test points, measurement equipment, and acceptable force limits. Every electric gate installation must have a documented force test to this standard.
Part P of the Building Regulations (Approved Document P)
The electrical supply to the gate (typically a new outdoor circuit with armoured cable) is notifiable electrical work under Part P. It must be installed by a qualified electrician registered with a competent person scheme and certified with an Electrical Installation Certificate.
What to expect
Frequently asked questions
Can I automate my existing manual gates?
Do I need planning permission for electric gates?
What happens if the power goes out?
Are electric gates safe for children and pets?
What is the difference between swing and sliding gates?
How often do electric gates need servicing?
